| Type | Single Ended Shear Beam |
| Material | Alloy Steel |
| Ingress Protection | IP66 |
| Application | Hopper Scales |
| Model | CZL803-M |
| Capacity | 1000 Kg |
| Features | Hermetically sealed |
| Output Sensitivity(FS) | 3.0 +/- 0.003 mV/V |
| Creep Error (30 minutes) | +/- 0.02% FS |
| Temperature Effect on Zero | +/-0.03% FS/DegC |
| Temperature Effect on Output | +/-0.02% FS/DegC |
| Zero balance | +/- 1% FS |
| Maximum Safe Overload | 150% FS |
| Ultimate Safe Overload | 200% FS |
| Recommended Excitation Voltage | 5 to 12V DC |
| Input Resistance | 350 +/- 10 Ohms |
| Output Resistance | 350 +/- 3 Ohms |
| Insulation resistance at 50V DC | >= 5000 M Ohm |
| Compensated Temperature Range | -10 to +40 Deg C |
| Operating Temperatue Range | -20 to +70 Deg C |
| Cable Length | 3 meter |
| HSN CODE | 8423 OR 9031 |
min. Order qty : 4pcs
no warrenty / gurrenty / return / replacement in loadcell
