| Capacity | 3kg |
| Material | Nickel Alloy Steel |
| Ingress Protection | IP65 |
| Application | Platform Scale |
| Output Sensitivity(FS) | 2.0 +/- 0.002 mV/V |
| Creep Error (30 minutes) | +/-0.03% FS |
| Temperature Effect on Zero | +/-0.0015% FS/DegC |
| Temperature Effect on Output | +/-0.002% FS |
| Zero balance | +/- 1% FS |
| Maximum Safe Overload | 150% FS |
| Ultimate Safe Overload | 250% FS |
| Recommended Excitation Voltage | 5 to 15V DC |
| Input Resistance | 390 +/- 15 Ohms |
| Output Resistance | 350 +/- 3 Ohms |
| Insulation resistance at 50V DC | >= 1000 M Ohm |
| Compensated Temperature Range | -10 to +40 Deg C |
| Operating Temperatue Range | -20 to +70 Deg C |
CUT SIZE LOADCELL
HALL CENTER SIZE : 25 X 25
CAPACITY : 100KG, 200KG, 300KG, 500KG
no warrenty / gurrenty / return / replacement in loadcell
